396-030 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 30POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Termination | Contact Type | Number of Positions/Bay/Row | Color | Read Out | Mounting Type | Features | Flange Feature | Pitch | Pitch | Number of Rows [custom] | Gender | Card Type | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Solder | Cantilever | 15 | Black | Dual | Through Hole | Card Guides | 4-40 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | 2 | Female | Non Specified - Dual Edge | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Wire Wrap | Cantilever | 30 | Black | Single | Through Hole | Card Guides | 4-40 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Female | Non Specified - Single Edge | 1 | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Solder | Cantilever | 30 | Black | Single | Through Hole | Card Guides | 4-40 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Female | Non Specified - Single Edge | 1 | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Solder Wire Wrap | Cantilever | 30 | Black | Single | Right Angle Through Hole | Floating Bobbin Top Mount Opening | 3.18 mm | 0.125 in | Female | Non Specified - Single Edge | 1 | 1 | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Solder | Cantilever | 30 | Black | Single | Through Hole | Flush Mount Top Opening Unthreaded | 3.18 mm | 0.125 in | Female | Non Specified - Single Edge | 1 | 1 | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Wire Wrap | Cantilever | 15 | Black | Dual | Through Hole | Card Guides | 4-40 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | 2 | Female | Non Specified - Dual Edge | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Solder Wire Wrap | Cantilever | 30 | Black | Single | Right Angle Through Hole | M3 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Female | Non Specified - Single Edge | 1 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Wire Wrap | Cantilever | 30 | Black | Single | Through Hole | Flush Mount Top Opening Unthreaded | 3.18 mm | 0.125 in | Female | Non Specified - Single Edge | 1 | 1 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Solder | Cantilever | 30 | Black | Single | Through Hole | 3.18 mm | 0.125 in | Female | Non Specified - Single Edge | 1 | 1 | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | 30 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Solder Wire Wrap | Cantilever | 30 | Black | Single | Right Angle Through Hole | 3.18 mm | 0.125 in | Female | Non Specified - Single Edge | 1 | 1 | 0.156 " | 3.96 mm |
