VMS-60 Series
Manufacturer: CUI Inc.
Beta
⌘K
AC/DC POWER SUPPLY SINGLE-OUT 12V 5A 60W MEDICAL 6-PIN
| Part | Power (Watts) | Voltage - Input [Max] | Voltage - Input [Min] | Applications | Number of Outputs | Operating Temperature [Max] | Operating Temperature [Min] | Standard Number | Efficiency | Voltage - Output 1 | Minimum Load Required | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Features | Voltage - Isolation | Approval Agency | Type | Current - Output 1 | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | 60 W | 264 VAC | 90 VAC | Medical | 1 | 70 °C | -20 °C | 55011 Class B 55024 55032 Class B 60601-1 60950-1 61000-3-2 61000-3-3 61000-6-1 61000-6-2 61000-6-3 61010-1 61204-3 | 87 % | 12 V | 1.1 inches 27.9 mm | 101.6 mm | 50.8 mm | Adjustable Output Universal Input | 5656 V | CB Scheme EN IEC SIQ TUV UL | Open Frame | 5 A | Chassis Mount | |
 CUI Inc. | 60 W | 264 VAC | 90 VAC | Medical | 1 | 70 °C | -20 °C | 55011 Class B 55024 55032 Class B 60601-1 60950-1 61000-3-2 61000-3-3 61000-6-1 61000-6-2 61000-6-3 61010-1 61204-3 | 88 % | 15 V | 1.1 inches 27.9 mm | 101.6 mm | 50.8 mm | Adjustable Output Universal Input | 5656 V | CB Scheme EN IEC SIQ TUV UL | Open Frame | 4 A | Chassis Mount |
