9443MN Series

Catalog

CABLE 3COND 20AWG YELLOW

Part	Ratings	Cable Type	Operating Temperature [Max]	Operating Temperature [Min]	Jacket Color	Usage	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Length [x]	Length [x]	Wire Gauge	Conductor Insulation	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Voltage	Length	Length
Belden Inc. 9443MN 004100	UL Style 2937	Multi-Conductor	80 °C	-20 ░C	Yellow	Audio Control Instrumentation	26	34 AWG	Poly-Vinyl Chloride (PVC)	0.155 in	3.94 mm	3	100 ft	30.5 m	20 AWG	Polypropylene (PP)	0.406 mm	0.016 in	Copper Tinned	300 VDC
Belden Inc. 9443MN 006100	UL Style 2937	Multi-Conductor	80 °C	-20 ░C	Blue	Audio Control Instrumentation	26	34 AWG	Poly-Vinyl Chloride (PVC)	0.155 in	3.94 mm	3	100 ft	30.5 m	20 AWG	Polypropylene (PP)	0.406 mm	0.016 in	Copper Tinned	300 VDC
Belden Inc. 9443MN 0081000	UL Style 2937	Multi-Conductor	80 °C	-20 ░C	Gray	Audio Control Instrumentation	26	34 AWG	Poly-Vinyl Chloride (PVC)	0.155 in	3.94 mm	3			20 AWG	Polypropylene (PP)	0.406 mm	0.016 in	Copper Tinned	300 VDC	304.8 m	1000 ft
