2823116 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

4P,2MM,BRK HDR,DRVT,2.8,0.1AU,TB

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Mating	Contact Length - Mating	Number of Positions Loaded	Connector Type	Voltage Rating	Mounting Type	Contact Shape	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Color	Pitch - Mating [x]	Pitch - Mating [x]	Contact Finish - Mating	Insulation Material	Number of Rows	Contact Finish - Post	Row Spacing - Mating	Row Spacing - Mating	Contact Material	Number of Positions	Contact Length - Post [x]	Contact Length - Post [x]	Termination	Fastening Type	Current Rating (Amps)	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Material Flammability Rating	Overall Contact Length	Overall Contact Length	Contact Type	Shrouding	Insulation Height	Insulation Height	Number of Positions
TE Connectivity Raychem Cable Protection 2823116-4	0.3 µm	12 µin	4 mm	0.157 in	All	Breakaway Header	125 VAC	Through Hole	Square	-40 °C	105 ░C	Black	0.079 in	2 mm	Gold	Thermoplastic	2	Tin	0.079 in	2 mm	Phosphor Bronze	4	0.11 in	2.8 mm	Solder	Push-Pull	2 A	3.94 µin	0.1 µm	UL94 V-0	8.3 mm	0.327 in	Male Pin	Unshrouded	1.5 mm	0.059 "
TE Connectivity Raychem Cable Protection 5-2823116-0	0.3 µm	12 µin	4 mm	0.157 in	All	Breakaway Header	125 VAC	Through Hole	Square	-40 °C	105 ░C	Black	0.079 in	2 mm	Gold	Thermoplastic	2	Tin	0.079 in	2 mm	Phosphor Bronze	50	0.11 in	2.8 mm	Solder	Push-Pull	2 A	3.94 µin	0.1 µm	UL94 V-0	8.3 mm	0.327 in	Male Pin	Unshrouded	1.5 mm	0.059 "
TE Connectivity Raychem Cable Protection 2823116-8	0.3 µm	12 µin	4 mm	0.157 in	All	Breakaway Header	125 VAC	Through Hole	Square	-40 °C	105 ░C	Black	0.079 in	2 mm	Gold	Thermoplastic	2	Tin	0.079 in	2 mm	Phosphor Bronze	8	0.11 in	2.8 mm	Solder	Push-Pull	2 A	3.94 µin	0.1 µm	UL94 V-0	8.3 mm	0.327 in	Male Pin	Unshrouded	1.5 mm	0.059 "
TE Connectivity Raychem Cable Protection 1-2823116-6	0.3 µm	12 µin	4 mm	0.157 in	All	Breakaway Header	125 VAC	Through Hole	Square	-40 °C	125 °C	Black	0.079 in	2 mm	Gold	Thermoplastic	2	Tin	0.079 in	2 mm	Phosphor Bronze		0.11 in	2.8 mm	Solder	Push-Pull	2 A	3.94 µin	0.1 µm	UL94 V-0	8.3 mm	0.327 in	Male Pin	Unshrouded	1.5 mm	0.059 "	16
TE Connectivity Raychem Cable Protection 1-2823116-2	0.3 µm	12 µin	4 mm	0.157 in	All	Breakaway Header	125 VAC	Through Hole	Square	-40 °C	125 °C	Black	0.079 in	2 mm	Gold	Thermoplastic	2	Tin	0.079 in	2 mm	Phosphor Bronze	12	0.11 in	2.8 mm	Solder	Push-Pull	2 A	3.94 µin	0.1 µm	UL94 V-0	8.3 mm	0.327 in	Male Pin	Unshrouded	1.5 mm	0.059 "
TE Connectivity Raychem Cable Protection 1-2823116-4	0.3 µm	12 µin	4 mm	0.157 in	All	Breakaway Header	125 VAC	Through Hole	Square	-40 °C	125 °C	Black	0.079 in	2 mm	Gold	Thermoplastic	2	Tin	0.079 in	2 mm	Phosphor Bronze	14	0.11 in	2.8 mm	Solder	Push-Pull	2 A	3.94 µin	0.1 µm	UL94 V-0	8.3 mm	0.327 in	Male Pin	Unshrouded	1.5 mm	0.059 "
