DDC114YUQ

DDC114YUQ Series

NRND = Not Recommended for New Design

Manufacturer: Diodes Inc

Catalog

NRND = Not Recommended for New Design

Catalog

NRND = Not Recommended for New Design

Part	Vce Saturation (Max) @ Ib, Ic	Qualification	Package / Case	Frequency - Transition	Mounting Type	Transistor Type	Resistor - Emitter Base (R2)	Current - Collector Cutoff (Max) [Max]	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Power - Max [Max]	Voltage - Collector Emitter Breakdown (Max) [Max]	Current - Collector (Ic) (Max) [Max]	Supplier Device Package	Grade	DC Current Gain (hFE) (Min) @ Ic, Vce
Diodes Inc DDC114YUQ-13-F	300 mV	AEC-Q101	6-TSSOP SC-88 SOT-363	250 MHz	Surface Mount	2 NPN - Pre-Biased (Dual)	47000 Ohms	500 nA	80	200 mW	50 V	100 mA	SOT-363	Automotive
Diodes Inc DDC114EU-7-F	300 mV		6-TSSOP SC-88 SOT-363	250 MHz	Surface Mount	2 NPN - Pre-Biased (Dual)	10 kOhms	500 nA		200 mW	50 V	100 mA	SOT-363		30 hFE
Diodes Inc DDC114TU-7	300 mV		6-TSSOP SC-88 SOT-363	250 MHz	Surface Mount	2 NPN - Pre-Biased (Dual)		500 nA	100	200 mW	50 V	100 mA	SOT-363
Diodes Inc DDC114EUQ-13-F	300 mV	AEC-Q101	6-TSSOP SC-88 SOT-363	250 MHz	Surface Mount	2 NPN - Pre-Biased (Dual)	10 kOhms	500 nA		200 mW	50 V	100 mA	SOT-363	Automotive	30 hFE
Diodes Inc DDC114YU-7-F	300 mV		6-TSSOP SC-88 SOT-363	250 MHz	Surface Mount	2 NPN - Pre-Biased (Dual)	47000 Ohms	500 nA	68	200 mW	50 V	100 mA	SOT-363
Diodes Inc DDC114EU-7	300 mV		6-TSSOP SC-88 SOT-363	250 MHz	Surface Mount	2 NPN - Pre-Biased (Dual)	10 kOhms	500 nA		200 mW	50 V	100 mA	SOT-363		30 hFE
Diodes Inc DDC114YUQ-7-F	300 mV	AEC-Q101	6-TSSOP SC-88 SOT-363	250 MHz	Surface Mount	2 NPN - Pre-Biased (Dual)	47000 Ohms	500 nA	80	200 mW	50 V	100 mA	SOT-363	Automotive
Diodes Inc DDC114EUQ-7-F	300 mV	AEC-Q101	6-TSSOP SC-88 SOT-363	250 MHz	Surface Mount	2 NPN - Pre-Biased (Dual)	10 kOhms	500 nA		200 mW	50 V	100 mA	SOT-363	Automotive	30 hFE
