396-017 Series
Manufacturer: EDAC Inc.
Beta
⌘K
396 SERIES (.125" (3.18MM) CONTA
| Part | Material - Insulation | Termination Rows | Mounting Type | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Color | Number of Positions/Bay/Row [custom] | Pitch | Pitch | Card Type | Contact Finish Thickness | Contact Finish Thickness | Gender | Contact Material | Number of Rows | Read Out | Termination | Flange Feature | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Solder | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Right Angle Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Solder Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Solder | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Solder | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Wire Wrap | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Solder | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Solder | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Wire Wrap | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Right Angle Through Hole | Cantilever | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 17 | 3.18 mm | 0.125 in | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Female | Copper Alloy | 1 | Single | Solder Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening |
