CKRD24 Series

Catalog

SSR RELAY SPST-NO 10A 24-280V

Part	Mounting Type	Load Current	Termination Style	Output Type	Voltage - Input [Max]	Voltage - Input [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Approval Agency	Voltage - Load [Min]	Voltage - Load [Max]
Sensata-Crydom CKRD2410P	DIN Rail	10 A	Screw Terminal	AC Zero Cross	32 VDC	4 V	80 °C	-40 C	SSR with Integrated Heat Sink	CE CSA TUV UR	24 V	280 V
Sensata-Crydom CKRD2430-10	DIN Rail	30 A	Screw Terminal	AC	32 VDC	4 V	80 °C	-40 C	SSR with Integrated Heat Sink	CE CSA TUV UR	24 V	280 V
Sensata-Crydom CKRD2430	DIN Rail	30 A	Screw Terminal	AC Zero Cross	32 VDC	4 V	80 °C	-40 C	SSR with Integrated Heat Sink	CE CSA TUV UR	24 V	280 V
Sensata-Crydom CKRD2430P-10	DIN Rail	30 A	Screw Terminal	AC	32 VDC	4 V	80 °C	-40 C	SSR with Integrated Heat Sink	CE CSA TUV UR	24 V	280 V
Sensata-Crydom CKRD2420	DIN Rail	20 A	Screw Terminal	AC Zero Cross	32 VDC	4 V	80 °C	-40 C	SSR with Integrated Heat Sink	CE CSA TUV UR	24 V	280 V
