395-053 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 53POS 0.100
| Part | Termination Rows | Material - Insulation | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Contact Material | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Gender | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Read Out | Pitch | Pitch | Mounting Type | Card Type | Features | Termination | Color | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | Card Guides | Wire Wrap | Black | 53 | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Right Angle Through Hole | Non Specified - Single Edge | Solder | Black | 53 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | Wire Wrap | Black | 53 | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | Solder | Black | 53 | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | Card Guides | Solder | Black | 53 | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | Card Guides | Solder | Black | 53 | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Side Mount Opening Unthreaded | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | Solder | Black | 53 | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Right Angle Through Hole | Non Specified - Single Edge | Solder | Black | 53 | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | Solder | Black | 53 | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | 1 | -40 C | 105 ░C | 53 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Single | 0.1 " | 2.54 mm | Through Hole | Non Specified - Single Edge | Solder | Black | 53 |
