SFH6345 Series

Catalog

OPTOISOLTR 5.3KV 1CH TRANS 8-SMD

Part	Output Type	Operating Temperature [Max]	Operating Temperature [Min]	Turn On / Turn Off Time (Typ) [custom]	Turn On / Turn Off Time (Typ) [custom]	Current Transfer Ratio (Min) [Min]	Supplier Device Package	Mounting Type	Input Type	Current - DC Forward (If) (Max) [Max]	Vce Saturation (Max) [Max]	Number of Channels	Voltage - Isolation	Voltage - Output (Max) [Max]	Current - Output / Channel [custom]	Package / Case	Package / Case	Package / Case	Package / Case
Vishay General Semiconductor - Diodes Division SFH6345-X007T	1.81 mOhm	100 °C	-55 °C	300 ns	300 ns	19 %	8-SMD	Surface Mount	DC	25 mA	400 mV	1	5300 Vrms	25 V	8 mA
Vishay General Semiconductor - Diodes Division SFH6345-X007	1.81 mOhm	100 °C	-55 °C	300 ns	300 ns	19 %	8-SMD	Surface Mount	DC	25 mA	400 mV	1	5300 Vrms	25 V	8 mA
Vishay General Semiconductor - Diodes Division SFH6345-X019T	1.81 mOhm	100 °C	-55 °C	300 ns	300 ns	19 %	8-SMD	Surface Mount	DC	25 mA	400 mV	1	5300 Vrms	25 V	8 mA
Vishay General Semiconductor - Diodes Division SFH6345-X001	1.81 mOhm	100 °C	-55 °C	300 ns	300 ns	19 %	8-DIP	Through Hole	DC	25 mA	400 mV	1	5300 Vrms	25 V	8 mA	0.3 in	8-DIP	7.62 mm
Vishay General Semiconductor - Diodes Division SFH6345-X017T	1.81 mOhm	100 °C	-55 °C	300 ns	300 ns	19 %	8-SMD	Surface Mount	DC	25 mA	400 mV	1	5300 Vrms	25 V	8 mA
Vishay General Semiconductor - Diodes Division SFH6345-X016	1.81 mOhm	100 °C	-55 °C	300 ns	300 ns	19 %	8-DIP	Through Hole	DC	25 mA	400 mV	1	5300 Vrms	25 V	8 mA	10.16 mm	8-DIP		10.16 mm
