2823394 Series

Catalog

9P,2MM,SHRD HDR,SRRT,2.8,0.76AU,

Part	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish - Post	Pitch - Mating [x]	Pitch - Mating [x]	Termination	Insulation Material	Current Rating (Amps)	Insulation Color	Contact Length - Post [x]	Contact Length - Post [x]	Contact Material	Contact Finish - Mating	Number of Positions	Insulation Height [custom]	Insulation Height [custom]	Number of Positions Loaded	Voltage Rating	Contact Length - Mating	Contact Length - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Fastening Type	Mounting Type	Contact Shape	Connector Type	Material Flammability Rating	Shrouding	Contact Type	Number of Rows
TE Connectivity Raychem Cable Protection 2823394-9	125 °C	-40 °C	157.5 Áin	4 Ám	Tin	0.079 in	2 mm	Solder	Thermoplastic	2 A	Black	0.11 in	2.8 mm	Phosphor Bronze	Gold	9	0.157 in	4 mm	All	125 VAC	4 mm	0.157 in	30 Áin	0.76 Ám	Detent Lock	Through Hole Right Angle	Square	Header	UL94 V-0	Shrouded - 2 Wall	Male Pin	1
TE Connectivity Raychem Cable Protection 2823394-7	125 °C	-40 °C	157.5 Áin	4 Ám	Tin	0.079 in	2 mm	Solder	Thermoplastic	2 A	Black	0.11 in	2.8 mm	Phosphor Bronze	Gold	7	0.157 in	4 mm	All	125 VAC	4 mm	0.157 in	30 Áin	0.76 Ám	Detent Lock	Through Hole Right Angle	Square	Header	UL94 V-0	Shrouded - 2 Wall	Male Pin	1
