TPS7A1010 Series
Manufacturer: Texas Instruments
Beta
⌘K
IC REG LINEAR 1V 300MA 5DSBGA
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Control Features | Supplier Device Package | Current - Quiescent (Iq) | Package / Case | Current - Output | Voltage - Input (Max) [Max] | Protection Features | Mounting Type | Current - Supply (Max) [Max] | Voltage - Output (Min/Fixed) | Number of Regulators | Output Configuration | PSRR [Min] | PSRR [Max] | Voltage Dropout (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | -40 C | 125 °C | Enable | 5-DSBGA | 2.6 µA | 5-XFBGA DSBGA | 300 mA | 3.3 V | Over Current Over Temperature UVLO | Surface Mount | 9 µA | 1 V | 1 | Positive | 35 dB | 60 dB | 0.07 V |
 Texas Instruments | -40 C | 125 °C | Enable | 2.6 µA | 6-WFDFN | 300 mA | 3.3 V | Over Current Over Temperature UVLO | Surface Mount | 9 µA | 1 V | 1 | Positive | 35 dB | 60 dB | 0.09 V |
