307-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 28POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Mounting Type | Contact Type | Gender | Read Out | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Termination | Color | Number of Positions/Bay/Row | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Termination Rows | Features | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Right Angle Through Hole | Semi Bellows | Female | Dual | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Non Specified - Dual Edge | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Solder Wire Wrap | Green | 14 | Copper Alloy | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Board Edge Straddle Mount | Semi Bellows | Female | Dual | 3.96 mm | 0.156 in | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Solder | Green | 14 | Copper Alloy | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Right Angle Through Hole | Semi Bellows | Female | Dual | 3.96 mm | 0.156 in | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | Solder | Green | 28 | Copper Alloy | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Right Angle Through Hole | Semi Bellows | Female | Dual | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Non Specified - Dual Edge | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | Solder | Green | 28 | Copper Alloy | 0.25 Ám | 10 Áin | 1 | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Through Hole | Semi Bellows | Female | Dual | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Non Specified - Dual Edge | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Solder | Green | 14 | Copper Alloy | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Board Edge Straddle Mount | Semi Bellows | Female | Dual | 3.96 mm | 0.156 in | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Non Specified - Dual Edge | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Solder Eyelet(s) | Green | 14 | Copper Alloy | 0.25 Ám | 10 Áin | Card Extender | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Board Edge Straddle Mount | Semi Bellows | Female | Dual | 3.96 mm | 0.156 in | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Solder Eyelet(s) | Green | 14 | Copper Alloy | Card Extender | ||||
 EDAC Inc. | Polyester Thermoplastic | Right Angle Through Hole | Semi Bellows | Female | Single | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 28 | Solder | Green | 28 | Copper Alloy | 0.25 Ám | 10 Áin | 1 | Card Guides | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Right Angle Through Hole | Semi Bellows | Female | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | -40 C | 105 ░C | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | Solder | Green | 28 | Copper Alloy | 1 | ||||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Surface Mount | Semi Bellows | Female | Dual | 3.96 mm | 0.156 in | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Non Specified - Dual Edge | -40 C | 105 ░C | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | Solder Eyelet(s) | Green | 28 | Copper Alloy | 0.25 Ám | 10 Áin | 1 |
