MT20E Series
Manufacturer: Volgen + Furuno
Beta
⌘K
DC DC CONVERTER 12V 20W
| Part | Type | Power (Watts) | Current - Output (Max) [Max] | Number of Outputs | Size / Dimension | Efficiency | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 1 | Voltage - Input (Min) [Min] | Applications | Package / Case | Mounting Type | Voltage - Input (Max) [Max] | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Volgen + Furuno | Isolated Module | 20 W | 1.67 A | 1 | 0.4 in 10.2 mm 25.4 mm 50.8 mm | 86 % | 66 °C | -40 C | 12 V | 9 V | ITE (Commercial) | 6-DIP Module | Through Hole | 36 V | 1.6 kV |
Volgen + Furuno | Isolated Module | 20 W | 4 A | 1 | 0.4 in 10.2 mm 25.4 mm 50.8 mm | 88 % | 66 °C | -40 C | 5 V | 9 V | ITE (Commercial) | 6-DIP Module | Through Hole | 36 V | 1.6 kV |
Volgen + Furuno | Isolated Module | 20 W | 1.33 A | 1 | 0.4 in 10.2 mm 25.4 mm 50.8 mm | 87 % | 66 °C | -40 C | 15 V | 18 V | ITE (Commercial) | 6-DIP Module | Through Hole | 75 V | 1.6 kV |
Volgen + Furuno | Isolated Module | 20 W | 1.33 A | 1 | 0.4 in 10.2 mm 25.4 mm 50.8 mm | 86 % | 66 °C | -40 C | 15 V | 9 V | ITE (Commercial) | 6-DIP Module | Through Hole | 36 V | 1.6 kV |
