M20-783 Series

Catalog

15+15 POS. FEMALE DIL VERTICAL THROUGHBOARD CONN. ROHS COMPLIANT: YES

Part	Applications	Insulation Material	Contact Shape	Contact Material	Mated Stacking Heights	Operating Temperature [Min]	Operating Temperature [Max]	Contact Type	Connector Type	Insulation Color	Contact Length - Post	Contact Length - Post	Material Flammability Rating	Termination	Mounting Type	Number of Positions Loaded	Style	Insulation Height	Insulation Height	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Voltage Rating	Current Rating (Amps)	Number of Rows [custom]	Number of Positions	Fastening Type	Contact Finish - Post	Pitch - Mating	Pitch - Mating	Contact Finish - Mating	Contact Finish Thickness - Mating
Harwin Inc. M20-7831546	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	30	Push-Pull	Tin	0.1 "	2.54 mm
Harwin Inc. M20-7830846	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	16	Push-Pull	Tin	0.1 "	2.54 mm
Harwin Inc. M20-7832042	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	40	Push-Pull	Tin	0.1 "	2.54 mm	Gold	Flash
Harwin Inc. M20-7830942	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	18	Push-Pull	Tin	0.1 "	2.54 mm	Gold	Flash
Harwin Inc. M20-7833646	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	72	Push-Pull	Tin	0.1 "	2.54 mm
Harwin Inc. M20-7830542	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	10	Push-Pull	Tin	0.1 "	2.54 mm	Gold	Flash
Harwin Inc. M20-7830446	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	8	Push-Pull	Tin	0.1 "	2.54 mm
Harwin Inc. M20-7831346	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	26	Push-Pull	Tin	0.1 "	2.54 mm
Harwin Inc. M20-7831242	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	24	Push-Pull	Tin	0.1 "	2.54 mm	Gold	Flash
Harwin Inc. M20-7831542	General Purpose Industrial Telecommunications	Nylon 6T Polyamide (PA6T)	Square	Phosphor Bronze	11.04 mm 12.63 mm	-40 C	105 ░C	Female Socket	Receptacle	Black	0.118 in	3 mm	UL94 V-0	Solder	Through Hole	All	Board to Board Cable	0.335 "	8.51 mm	0.1 in	2.54 mm	1000 VDC	3 A	2	30	Push-Pull	Tin	0.1 "	2.54 mm	Gold	Flash
