E2E-X12 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR INDUCT 12MM PNP M18 NC
| Part | Sensor Type | Output Type | Output Type | Termination Style | Package / Case | Shielding | Material - Body | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Supply [Min] | Voltage - Supply [Max] | Indicator | Ingress Protection | Response Frequency | Sensing Distance | Sensing Distance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | Inductive | 3 | PNP-NC | Connector | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm |
 Omron Automation and Safety | Inductive | 3-Wire NPN-NC | Cable Leads | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm | |
Omron Automation and Safety | Inductive | 3 | PNP-NO | Cable with Connector | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm |
Omron Automation and Safety | Inductive | 3 | PNP-NO | Cable Leads | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm |
 Omron Automation and Safety | Inductive | 3-Wire NPN-NO | Cable Leads | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm | |
Omron Automation and Safety | Inductive | 3-Wire NPN-NO | Cable Leads | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm | |
Omron Automation and Safety | Inductive | 3-Wire NPN-NO | Cable with Connector | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm | |
Omron Automation and Safety | Inductive | 3-Wire NPN-NC/NO | Cable Leads | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm | |
Omron Automation and Safety | Inductive | 3 | PNP-NO | Cable Leads | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm |
Omron Automation and Safety | Inductive | 3-Wire PNP-NC/NO | Cable with Connector | Cylinder Threaded - M18 | Shielded | Nickel-Plated Brass | -25 °C | 70 °C | 10 VDC | 30 VDC | LED | IP67 IP69K | 500 Hz | 0.472 in | 12 mm |
