625-037 Series
Manufacturer: EDAC Inc.
Beta
⌘K
625 SERIES RIGHT ANGLE D-SUB PLU
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Contact Type | Shell Size, Connector Layout | Shell Size, Connector Layout | Features | Mounting Type | Shell Material, Finish | Termination | Connector Type | Flange Feature | Backset Spacing | Backset Spacing | Material Flammability Rating | Contact Finish | Number of Rows [custom] | Current Rating (Amps) | Connector Style | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Signal | 4 | DC C | Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | 4-40 | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 30 Áin | 0.76 Ám | 37 | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Signal | 4 | DC C | Board Lock Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | Housing/Shell (M3) | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 15 µin | 0.38 µm | 37 | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | Signal | 4 | DC C | Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | 4-40 Mating Side Female Screwlock | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 37 | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Signal | 4 | DC C | Board Lock Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | Housing/Shell (M3) | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 30 Áin | 0.76 Ám | 37 | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | Signal | 4 | DC C | Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | Housing/Shell (Unthreaded) | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 15 µin | 0.38 µm | 37 | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | Signal | 4 | DC C | Board Lock Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | Housing/Shell | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 30 Áin | 0.76 Ám | 37 | 4-40 | |
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Signal | 4 | DC C | Board Lock Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | Housing/Shell | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 15 µin | 0.38 µm | 37 | 4-40 | |
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | Signal | 4 | DC C | Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | Housing/Shell (Unthreaded) | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 30 Áin | 0.76 Ám | 37 | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Black | Copper Alloy | Signal | 4 | DC C | Board Lock Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | 4-40 Mating Side Female Screwlock | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 15 µin | 0.38 µm | 37 | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Copper Alloy | Signal | 4 | DC C | Board Lock Grounding Indents Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Nickel Plated Steel | Solder | Plug Male Pins | 4-40 Mating Side Female Screwlock | 0.584 " | 14.84 mm | UL94 V-0 | Gold | 2 | 3 A | D-Sub | 15 µin | 0.38 µm | 37 |
