307-070 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, DUAL SIDE, 1.57 MM, 70 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
| Part | Material - Insulation | Termination Rows [custom] | Mounting Type | Contact Type | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Features | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Card Type | Pitch | Pitch | Number of Rows [custom] | Contact Finish | Number of Positions | Color | Termination | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Board Edge Straddle Mount | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 0.25 Ám | 10 Áin | 35 | Card Extender | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Gold | 70 | Green | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 0.25 Ám | 10 Áin | 35 | Card Guides | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Gold | 70 | Green | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 0.25 Ám | 10 Áin | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Gold | 70 | Green | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Board Edge Straddle Mount | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 0.25 Ám | 10 Áin | 35 | Card Extender Card Guides | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Gold | 70 | Green | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 0.25 Ám | 10 Áin | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Side Opening Unthreaded | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Gold | 70 | Green | Wire Wrap | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Tin | 70 | Green | Wire Wrap | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 0.25 Ám | 10 Áin | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Gold | 70 | Green | Wire Wrap | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Tin | 70 | Green | Solder | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Tin | 70 | Green | Solder | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | Semi Bellows | Dual | -40 C | 105 ░C | Female | Copper Alloy | 35 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 2 | Tin | 70 | Green | Solder Eyelet(s) |
