112217 Series
Manufacturer: Molex
Beta
⌘K
ARC 60A F 347/600VAC 3P+N
| Part | Insert Material | Connector Type | Features | Current Rating (Amps) | Primary Material | Shell Material | Fastening Type | Color | Ingress Protection | Orientation | Mounting Feature | Contact Material | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Contact Finish - Mating | Shielding | Number of Positions | Mounting Type | Voltage Rating | Backshell Material, Plating | Number of Positions [custom] | Number of Positions [custom] | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Polybutylene Terephthalate (PBT) Glass Filled | Receptacle Female Sockets | Cap (Cover) | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 14 | Flange | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | 5 | ||||||
 Molex | Polybutylene Terephthalate (PBT) Glass Filled | Receptacle Female Sockets | Backshell Cap (Cover) | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 7 | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | Free Hanging (In-Line) | 250 VAC | Glass Filled Polybutylene Terephthalate (PBT) | 2 | 3 | 1 | ||
Molex | Polybutylene Terephthalate (PBT) Glass Filled | Receptacle Female Sockets | Cap (Cover) | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 4 | Flange | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | 4 | 480 VAC | |||||
 Molex | Polybutylene Terephthalate (PBT) Glass Filled | Receptacle Female Sockets | Backshell Cap (Cover) | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 16 | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | 5 | Free Hanging (In-Line) | Glass Filled Polybutylene Terephthalate (PBT) | |||||
 Molex | Polybutylene Terephthalate (PBT) Glass Filled | Male Pins Plug | Backshell Cap (Cover) | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 4 | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | 4 | Free Hanging (In-Line) | 480 VAC | Glass Filled Polybutylene Terephthalate (PBT) | ||||
Molex | Polybutylene Terephthalate (PBT) Glass Filled | Male Pins Plug | Backshell Cap (Cover) | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 4 | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | Free Hanging (In-Line) | 480 VAC | Glass Filled Polybutylene Terephthalate (PBT) | 2 | 3 | 1 | ||
 Molex | Polybutylene Terephthalate (PBT) Glass Filled | Male Pins Plug | Backshell Cap (Cover) | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 4 | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | Free Hanging (In-Line) | 277 VAC/DC | Glass Filled Polybutylene Terephthalate (PBT) | 2 | 3 | 1 | ||
 Molex | Polybutylene Terephthalate (PBT) Glass Filled | Male Pins Plug | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 4 | Flange | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | 5 | |||||||
Molex | Polybutylene Terephthalate (PBT) Glass Filled | Receptacle Female Sockets | Backshell Cap (Cover) | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 14 | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | 4 | Free Hanging (In-Line) | 600 VAC | Glass Filled Polybutylene Terephthalate (PBT) | ||||
Molex | Polybutylene Terephthalate (PBT) Glass Filled | Male Pins Plug | 60 A | Plastic | Polybutylene Terephthalate (PBT) Glass Filled | Push-Twist | Gray | IP69K - Dust Tight High Temp Water Jets Waterproof | 16 | Flange | Copper Alloy | Industrial | -25 °C | 60 °C | Screw | Silver | Unshielded | 208 VAC | 2 | 3 | 1 |
