315-062 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, DUAL SIDE, 1.57 MM, 62 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
| Part | Material - Insulation | Termination Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Number of Rows [custom] | Number of Positions | Color | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row [custom] | Gender | Mounting Type | Contact Material | Termination | Card Type | Pitch | Pitch | Contact Type | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Panel Mount Through Hole | Copper Alloy | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | Floating Bobbin Flush Mount | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Panel Mount Through Hole | Copper Alloy | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold | 0.116 " | 2.95 mm |
EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | Floating Bobbin Flush Mount | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Panel Mount Through Hole | Copper Alloy | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold | 0.116 " | 2.95 mm |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Panel Mount Through Hole | Copper Alloy | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Panel Mount | Copper Alloy | Solder Eyelet(s) | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Through Hole | Copper Alloy | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Panel Mount Through Hole | Copper Alloy | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Panel Mount Through Hole | Copper Alloy | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold | 0.128 " | 3.25 mm |
EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Through Hole | Copper Alloy | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold | |||
EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | 2 | 62 | Green | 0.25 Ám | 10 Áin | 31 | Female | Panel Mount | Copper Alloy | Solder Eyelet(s) | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Semi Bellows | Gold |
