POE16R Series
Manufacturer: Phihong USA
Beta
⌘K
POE INJECTOR 15.4W 56V WALL
| Part | Input Connector | Output Connector | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Output | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Approval Agency | Data Rate | Mounting Type | Type | Features | Number of Ports | Compliance | Power (Watts) - Per Port | Current - Output | Efficiency | Data Rate [Min] | Data Rate [Max] | Note | Weight | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phihong USA | International AC Clips (Power) RJ45 (Data) | RJ45 (Data Power) | 45 °C | -20 ░C | 264 VAC | 90 VAC | 56 V | 3.39 " | 86 mm | 1.31 " | 50.2 mm | 1.98 " | 33.2 mm | CE cUL cULus UL | 2.5 Gbps | Wall Mount | Midspan Injector | OCP OVP SCP | 1 | IEEE802.3af | 15.4 W | 275 mA | Level VI | |||||
 Phihong USA | RJ45 (Data) | RJ45 (Data Power) | 40 °C | 0 °C | 264 VAC | 90 VAC | 56 V | 3.39 " | 86 mm | 1.31 " | 50.2 mm | 1.98 " | 33.2 mm | C-Tick CE cULus SAA | Wall Mount | Passive Injector | OCP OVP SCP | 1 | IEEE802.3af | 16 W | 286 mA | Level VI | 10 Mbps | 100 Mbps | AC Power Clips Sold Separately | 0.209 lb | 94.8 g | |
 Phihong USA | 40 °C | 0 °C | 264 VAC | 90 VAC | 56 V | 3.39 " | 86 mm | 1.31 " | 50.2 mm | 1.98 " | 33.2 mm | C-Tick CE cULus SAA | Wall Mount | Passive Injector | OCP OVP SCP | 1 | IEEE802.3af | 16 W | 286 mA | Level VI | 10 Mbps | 100 Mbps |
