317-87 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 37POS 0.07 GOLD PCB
| Part | Contact Material | Insulation Material | Contact Shape | Contact Length - Post | Contact Length - Post | Material Flammability Rating | Termination | Insulation Height | Insulation Height | Fastening Type | Pitch - Mating | Pitch - Mating | Number of Positions Loaded | Contact Finish - Post | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type | Insulation Color | Contact Type | Number of Rows | Contact Finish - Mating | Mounting Type | Number of Positions | Contact Finish Thickness - Mating | Number of Positions [custom] | Contact Length - Post [x] | Contact Length - Post [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | 0.125 in | 3.18 mm | UL94 V-0 | Solder | 0.165 in | 4.2 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | 37 | Flash | |||
 Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | UL94 V-0 | Solder | 0.335 " | 8.51 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | Flash | 34 | 0.126 " | 3.2 mm | |||
 Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | 0.125 in | 3.18 mm | UL94 V-0 | Solder | 0.165 in | 4.2 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | 15 | Flash | |||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | 0.125 in | 3.18 mm | UL94 V-0 | Solder | 0.165 in | 4.2 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | 29 | Flash | |||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | 0.125 in | 3.18 mm | UL94 V-0 | Solder | 0.165 in | 4.2 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | 14 | Flash | |||
 Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | 4 mm | UL94 V-0 | Solder | 0.394 " | 10 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | 12 | Flash | 0.157 in | |||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | 0.125 in | 3.18 mm | UL94 V-0 | Solder | 0.165 in | 4.2 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | 12 | Flash | |||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | UL94 V-0 | Solder | 0.335 " | 8.51 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | 10 | Flash | 0.126 " | 3.2 mm | |||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | 0.125 in | 3.18 mm | UL94 V-0 | Solder | 0.165 in | 4.2 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | 10 | Flash | |||
Preci-Dip | Beryllium Copper | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | 0.125 in | 3.18 mm | UL94 V-0 | Solder | 0.165 in | 4.2 mm | Push-Pull | 0.07 in | 1.78 mm | All | Tin | -55 C | 125 °C | Socket | Black | Female Socket | 1 | Gold | Through Hole | 16 | Flash |
