c87 Series

Manufacturer: KEMET

Catalog

CAPACITOR: POLYPROPYLENE; MOTORS, RUN; 25UF; 470V; Ø48X98MM; ±5%

Part	Dielectric Material	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating - AC	Capacitance	Applications	Lead Spacing	Lead Spacing	Size / Dimension [diameter]	Size / Dimension [diameter]	Tolerance	Mounting Type	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET C878BF35250AA0J	Polypropylene (PP) Metallized	3.937 in	100 mm	85 °C	-25 °C	470 V	25 µF	Motor Run	0.528 in	13.4 mm	45 mm	1.772 "	5 %	Chassis Stud Mount	Can Radial
KEMET C878BF35120AA0J	Polypropylene (PP) Metallized			85 °C	-25 °C	470 V	12 µF	Motor Run	0.528 in	13.4 mm	35 mm	1.378 "	5 %	Chassis Stud Mount	Can Radial	3.15 "	80 mm
