833-023 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 23POS 0.156
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Card Type | Color | Number of Rows | Number of Positions | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Gender | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Mounting Type | Contact Material | Read Out | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Wire Wrap |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | M3 Threaded Insert Top Mount Opening | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Solder | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | 0.128 " | 3.25 mm | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Wire Wrap | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | Flush Mount M3 Threaded Insert Top Opening | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Solder | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | 4-40 Flush Mount Threaded Insert Top Opening | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Right Angle Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Solder | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Solder |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | 4-40 Threaded Insert Top Mount Opening | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Wire Wrap | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | 0.128 " | 3.25 mm | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Wire Wrap | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | Flush Mount M3 Threaded Insert Top Opening | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Wire Wrap | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Non Specified - Single Edge | Green | 1 | 23 | Flush Mount M3 Threaded Insert Top Opening | Female | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Copper Alloy | Single | 23 | 125 °C | -40 C | Wire Wrap |
