307-056 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 56POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Color | Contact Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Gender | Termination | Contact Finish | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Number of Rows [custom] | Number of Positions | Pitch | Pitch | Mounting Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Solder | Gold | 28 | 0.25 Ám | 10 Áin | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Right Angle Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Solder | Tin | 28 | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Through Hole | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Solder | Gold | 28 | 0.25 Ám | 10 Áin | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Board Edge Straddle Mount | Card Extender |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Solder | Gold | 28 | 0.25 Ám | 10 Áin | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Right Angle Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Wire Wrap | Gold | 28 | 0.25 Ám | 10 Áin | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Through Hole | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Solder | Gold | 28 | 0.25 Ám | 10 Áin | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Right Angle Through Hole | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | Flush Mount M3 Threaded Insert Top Opening | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Wire Wrap | Gold | 28 | 0.25 Ám | 10 Áin | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Through Hole | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Solder Eyelet(s) | Tin | 28 | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Through Hole | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Solder | Gold | 28 | 0.25 Ám | 10 Áin | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Dual | -40 C | 105 ░C | Non Specified - Dual Edge | Female | Solder | Gold | 28 | 0.25 Ám | 10 Áin | Copper Alloy | 2 | 56 | 3.96 mm | 0.156 in | Through Hole | Card Guides |
