68423 Series

Catalog

CONN HEADER R/A 17POS 2.54MM

Part	Contact Material	Contact Finish - Mating	Contact Type	Mounting Type	Material Flammability Rating	Contact Shape	Insulation Color	Connector Type	Contact Length - Mating [x]	Contact Length - Mating [x]	Contact Length - Post [x]	Contact Length - Post [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Insulation Height [z]	Insulation Height [z]	Termination	Fastening Type	Number of Rows	Number of Positions Loaded	Shrouding	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating (Amps)
Amphenol ICC (FCI) 68423-117HLF	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded
Amphenol ICC (FCI) 68423-108HLF	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded	8
Amphenol ICC (FCI) 68423-129HLF	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded	29
Amphenol ICC (FCI) 68423-104HLF	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded	4
Amphenol ICC (FCI) 68423-210	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	15 µin	0.38 µm	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded	10	-65 ░C	130 °C	3 A
Amphenol ICC (FCI) 68423-113HLF	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded	13	-65 ░C	130 °C	3 A
Amphenol ICC (FCI) 68423-102HTLF	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded	2	-65 ░C	130 °C	3 A
Amphenol ICC (FCI) 68423-106HLF	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded	6
Amphenol ICC (FCI) 68423-118HLF	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded	18
Amphenol ICC (FCI) 68423-136H	Phosphor Bronze	Gold or Gold GXT™	Male Pin	Through Hole Right Angle	UL94 V-0	Square	Black	Header	0.318 "	8.08 mm	0.12 in	3.05 mm	30 Áin	0.76 Ám	0.1 in	2.54 mm	0.095 in	2.41 mm	Solder	Push-Pull	1	All	Unshrouded	36	-65 ░C	130 °C	3 A
