KPSE Series

Catalog

CIRCULAR MIL SPEC CONNECTOR CONNECTOR

...

Part	Shell Material	Shell Size - Insert	Fastening Type	Orientation	Voltage Rating	Voltage Rating	Mounting Type	Primary Material	Shell Finish	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Color	Connector Type	Contact Finish - Mating	Number of Positions	Features	Applications	Contact Material	Insert Material	Shielding	Mounting Feature	Ingress Protection	Shell Size - Insert [Max]	Shell Size - Insert [Min]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Cable Opening	Cable Opening	Note	Type	Shell Size - Insert [Max] [custom]	Shell Size - Insert [Min] [custom]	Contact Type	Contact Shape	Housing Color	Contact Size
ITT Cannon, LLC KPSE06A10-6S	Aluminum Alloy	10-6	Bayonet Lock	N (Normal)	600 VAC	850 VDC	Free Hanging (In-Line)	Metal	Olive Drab Cadmium	7.5 A	-55 C	125 °C	Crimp	Olive Drab	Plug Female Sockets	Gold	6	Backshell
ITT Cannon, LLC KPSE00E16-8SDZ	Aluminum Alloy	16-8	Bayonet Lock	N (Normal)	1000 VAC 1400 V		Panel Mount	Metal	Olive Drab Cadmium	13 A	-55 C	125 °C	Crimp	Olive Drab	Receptacle Female Sockets	Gold	8	Coupling Nut Shrink Boot Adapter	Aerospace Industrial Instrumentation Medical Military	Copper Alloy	Polychloroprene	Shielded	Flange	IP67 - Dust Tight Waterproof
ITT Cannon, LLC KPSE6F10-6P-DX
ITT Cannon, LLC KPSE0E2255S-DZF42	Aluminum Alloy		Bayonet Lock	N (Normal)	600 VAC	850 VDC	Panel Mount	Metal	Olive Drab Cadmium	7.5 A	-55 C	125 °C	Crimp	Olive Drab	Receptacle Female Sockets	Gold	55	Shrink Boot Adapter	Aerospace Industrial Instrumentation Medical Military	Copper Alloy	Polychloroprene	Shielded	Flange	IP67 - Dust Tight Waterproof	55	22
ITT Cannon, LLC KPSE0E106S-DZBM221	Aluminum Alloy	10-6	Bayonet Lock	N (Normal)	600 VAC	850 VDC	Panel Mount	Metal	Olive Drab Chromate over Cadmium	7.5 A	-55 C	125 °C	Crimp	Olive Drab	Receptacle Female Sockets	Gold	6	Shrink Boot Adapter	Industrial Military	Copper Alloy	Polychloroprene	Shielded	Flange	IP67 - Dust Tight Waterproof			50 µin	1.27 µm
ITT Cannon, LLC KPSE06F20A6S	Aluminum Alloy	20-A6	Bayonet Lock	N (Normal)	1000 VAC 1400 V		Free Hanging (In-Line)	Metal	Olive Drab Chromate over Cadmium	23 A	-55 C	125 °C	Crimp	Olive Drab	Plug Female Sockets	Gold	5	Backshell Cable Clamp Coupling Nut Strain Relief	Industrial Military	Copper Alloy	Polychloroprene	Unshielded		IP67 - Dust Tight Waterproof			50 µin	1.27 µm	0.614 in	15.6 mm
ITT Cannon, LLC KPSE06J10-6P	Aluminum Alloy	10-6	Bayonet Lock	N (Normal)	600 VAC	850 VDC	Free Hanging (In-Line)	Metal	Olive Drab Cadmium	7.5 A	-55 C	125 °C	Crimp	Olive Drab	Plug Male Pins	Gold	6	Backshell Strain Relief						Environment Resistant			50 µin	1.27 µm
ITT Cannon, LLC KPSE00J22-21P	Aluminum Alloy		Bayonet Lock	N (Normal)	1000 VAC 1400 V		Panel Mount	Metal	Olive Drab Cadmium	13 A	-55 C	125 °C	Crimp	Olive Drab	Receptacle Male Pins	Gold	21	Backshell Strain Relief					Flange	Environment Resistant	21	22	50 µin	1.27 µm
ITT Cannon, LLC KPSE0E1419S-DNF0	Aluminum Alloy		Bayonet Lock	N (Normal)			Panel Mount		Chromate over Cadmium		-55 C	125 °C			Receptacle Housing		19	Backshell Shrink Boot Adapter			Polychloroprene	Unshielded	Flange	Environment Resistant							Contacts Not Included	For Female Sockets	19	14	Crimp	Circular	Olive Drab	20
ITT Cannon, LLC KPSE00F18-32SF42F0
