S11M07-P Series

Manufacturer: ODU

Catalog

Catalog

CONN PLUG MALE 2P GOLD SLDR CUP

...

Part	Shell Material	Contact Finish - Mating	Mounting Type	Ingress Protection	Features	Connector Type	Insert Material	Primary Material	Operating Temperature [Max]	Operating Temperature [Min]	Fastening Type	Orientation	Contact Material	Shell Size - Insert	Number of Positions	Applications	Backshell Material, Plating	Cable Opening [Max]	Cable Opening [Min]	Cable Opening [Max]	Cable Opening [Min]	Shielding	Current Rating (Amps)	Material Flammability Rating	Color	Cable Opening	Voltage Rating	Cable Opening [Max]
ODU S11M07-P02MPH0-6580	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1	2	Industrial Medical Military Testing Equipment & Measurement	Polysulfone (PSU)	6.5 mm	0.209 in	0.256 in	5.3 mm	Unshielded	14 A
ODU S11M07-P09MCD0-5260	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1	9	Industrial Medical Testing Equipment & Measurement	Polysulfone (PSU)		0.157 in	0.205 in		Unshielded	6 A	UL94 V-0	Blue Gray	4 mm 5.2 mm	16 VDC
ODU S11M07-P06MFD0-3920	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1	6	Industrial Medical Military Testing Equipment & Measurement	Polysulfone (PSU)		0.106 in	0.154 in	2.7 mm	Unshielded	4.55 A		Gray Red			3.9 mm
ODU S11M07-P07MFD0-5270	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1	7	Industrial Medical Military Testing Equipment & Measurement	Polysulfone (PSU)		0.157 in	0.205 in		Unshielded	4.55 A		Gray	4 mm 5.2 mm
ODU S11M07-P08MFD0-3930	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1	8	Industrial Medical Military Testing Equipment & Measurement	Polysulfone (PSU)		0.106 in	0.154 in	2.7 mm	Unshielded	3.85 A		Gray White			3.9 mm
ODU S11M07-P03MPH9-5260	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1		Industrial Medical Testing Equipment & Measurement	Polysulfone (PSU)		0.157 in	0.205 in		Unshielded	12 Amps	UL94 V-0	Blue Gray	4 mm 5.2 mm	48 VDC
ODU S11M07-P02MPH0-5280	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1	2	Industrial Medical Military Testing Equipment & Measurement	Polysulfone (PSU)		0.157 in	0.205 in		Unshielded	14 A			4 mm 5.2 mm
ODU S11M07-P03LJN0-6560	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1		Industrial Medical Testing Equipment & Measurement	Polysulfone (PSU)	6.5 mm	0.209 in	0.256 in	5.3 mm	Unshielded	10 A	UL94 V-0	Blue Gray		230 V
ODU S11M07-P08MFG0-3920	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1	8	Industrial Medical Military Testing Equipment & Measurement	Polysulfone (PSU)		0.106 in	0.154 in	2.7 mm	Unshielded			Gray Red			3.9 mm
ODU S11M07-P06MFD0-3940	Polysulfone (PSU)	Gold	Free Hanging (In-Line)	IP50 - Dust Protected	Backshell	Plug Male Pins	Polyetheretherketone (PEEK)	Plastic	120 °C	-50 °C	Push-Pull	0	Brass	1	6	Industrial Medical Military Testing Equipment & Measurement	Polysulfone (PSU)		0.106 in	0.154 in	2.7 mm	Unshielded	4.55 A		Gray Yellow			3.9 mm
