163A187 Series
Manufacturer: Amphenol CONEC
Beta
⌘K
CONN D-SUB PLUG 50POS R/A SLDR
| Part | Shell Size, Connector Layout | Current Rating (Amps) | Backset Spacing | Backset Spacing | Dielectric Material | Connector Type | Connector Style | Termination | Contact Finish Thickness | Contact Finish Thickness | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Contact Material | Contact Finish | Flange Feature | Color | Contact Type | Features | Mounting Type | Number of Rows | Voltage Rating | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol CONEC | 5 | 7.5 A | 9.4 mm | 0.37 in | Polybutylene Terephthalate (PBT) Glass Filled | Male Pins Plug | D-Sub | Solder | 8 çin | 0.203 çm | UL94 V-0 | -55 °C | 125 °C | 50 | Copper Alloy | Gold | Housing/Shell (4-40) | Black | Signal | Board Lock Grounding Indents | Board Edge Right Angle Through Hole | 3 | 125 VDC | ||
 Amphenol CONEC | Male Pins Plug | D-Sub | Solder | -55 °C | 125 °C | Gold | Housing/Shell (4-40) | Signal | Grounding Indents | Through Hole Right Angle | 2 | 125 VDC | B DB | 3 |
