842-058 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 58POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Read Out | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Positions/Bay/Row | Mounting Type | Contact Type | Color | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Termination | Card Type | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Gender | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Features | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 29 | Through Hole | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | Flush Mount M3 Threaded Insert Top Opening | 29 | Board Edge Straddle Mount | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Card Extender | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 58 | Through Hole | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Non Specified - Single Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | 4-40 Flush Mount Threaded Insert Top Opening | 58 | Through Hole | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Non Specified - Single Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 29 | Right Angle Through Hole | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | 4-40 Flush Mount Threaded Insert Top Opening | 58 | Through Hole | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Non Specified - Single Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 58 | Through Hole | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Non Specified - Single Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 29 | Board Edge Straddle Mount | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Dual | 4-40 Flush Mount Threaded Insert Top Opening | 29 | Through Hole | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Single | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 58 | Through Hole | Cantilever | Green | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Non Specified - Single Edge | 0.1 " | 2.54 mm | 125 °C | -40 C | Gold | Female | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 |
