316-031 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 31 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
| Part | Termination Rows | Material - Insulation | Color | Pitch | Pitch | Number of Positions/Bay/Row [custom] | Mounting Type | Contact Type | Termination | Flange Feature | Read Out | Card Thickness [Max] | Card Thickness [Min] | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Gender | Contact Material | Number of Rows [custom] | Contact Finish | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Through Hole | Cantilever | Solder | Flush Mount M3 Threaded Insert Top Opening | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | Copper Alloy | 2 | Gold | 62 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Panel Mount Through Hole | Cantilever | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | Copper Alloy | 2 | Gold | 62 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Panel Mount Through Hole | Cantilever | Solder | Flush Mount Side Opening Unthreaded | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | Copper Alloy | 2 | Gold | 62 | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Panel Mount Through Hole | Cantilever | Solder | Flush Mount M3 Threaded Insert Top Opening | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | Copper Alloy | 2 | Gold | 62 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Panel Mount Through Hole | Cantilever | Solder | Floating Bobbin Flush Mount | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | Female | Copper Alloy | 2 | Tin | 62 | 0.116 " | 2.95 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Through Hole | Cantilever | Solder | Flush Mount Top Opening Unthreaded | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | Copper Alloy | 2 | Gold | 62 | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Through Hole | Cantilever | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | Copper Alloy | 2 | Gold | 62 | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Through Hole | Cantilever | Solder | Flush Mount Top Opening Unthreaded | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | Copper Alloy | 2 | Gold | 62 | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Panel Mount | Cantilever | Solder Eyelet(s) | 4-40 Flush Mount Threaded Insert Top Opening | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | Copper Alloy | 2 | Gold | 62 | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Green | 3.96 mm | 0.156 in | 31 | Panel Mount | Cantilever | Solder Eyelet(s) | Flush Mount Side Opening Unthreaded | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | Copper Alloy | 2 | Gold | 62 | 0.128 " | 3.25 mm |
