Toggle Switches 3P (ON)-OFF-(ON) NEOPRENE SEAL
Toggle Switches 3P (ON)-OFF-(ON) NEOPRENE SEAL
| Part | Actuator Material | Electrical Life | Voltage Rating - AC | Mounting Type | Current Rating (Amps) | Illumination | Circuit | Actuator Length [x] | Bushing Thread | Switch Function | Termination Style | Actuator Type | Operating Temperature [Min] | Operating Temperature [Max] | Panel Cutout Dimensions [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Carling Technologies | Brass Nickel Plated | 25000 Steps | 125 V | Panel Mount | 15 A | Non-Illuminated | 3PDT | 17.45 mm | 15/32-32 | Mom-Off-Mom | Screw Terminal | Standard Round | 0 °C | 85 °C | 12.7 mm |
 Carling Technologies | Brass Nickel Plated | 50000 Cycles | 125 V | Panel Mount | 17 A | Non-Illuminated | 3PDT | 17.45 mm | 15/32-32 | On-On | Quick Connect - 0.250" (6.3mm) | Standard Round | 0 °C | 85 °C | 12.7 mm |
 Carling Technologies | 125 V | Panel Mount | 15 A | Non-Illuminated | 3PST | 17.45 mm | 15/32-32 | On-Off | Quick Connect - 0.250" (6.3mm) | Standard Round | 0 °C | 85 °C | 12.7 mm |
