580-M09 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN MICRO-D FEMALE 9P VRT PCB 3
| Part | Color | Voltage Rating | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Contact Type | Shell Material, Finish | Material Flammability Rating | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Number of Positions | Current Rating (Amps) | Connector Type | Connector Style | Features | Flange Feature | Mounting Type | Contact Finish | Shell Size, Connector Layout [y] | Shell Size, Connector Layout [x] | Termination | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Black | 60 VDC | Liquid Crystal Polymer (LCP) | 125 °C | -40 C | Brass | Signal | Nickel Plated Zinc Alloy | UL94 V-0 | 30 Áin | 0.76 Ám | 2 | 9 | 2 A | Receptacle Female Sockets | D-Type Micro-D | Shielded | Housing/Shell (Unthreaded) | Panel Mount Through Hole | Gold | 0.043 in | 0.05 in | Solder | |
 NorComp Inc. | Black | 60 VDC | Liquid Crystal Polymer (LCP) | 125 °C | -40 C | Brass | Signal | Nickel Plated Zinc Alloy | UL94 V-0 | 30 Áin | 0.76 Ám | 2 | 9 | 2 A | Plug Male Pins | D-Type Micro-D | Shielded | Housing/Shell (Unthreaded) | Panel Mount Through Hole | Gold | 0.043 in | 0.05 in | Solder | |
 NorComp Inc. | Black | 60 VDC | Liquid Crystal Polymer (LCP) | 125 °C | -40 C | Brass | Signal | Nickel Plated Zinc Alloy | UL94 V-0 | 15 µin | 0.38 µm | 2 | 9 | 2 A | Plug Male Pins | D-Type Micro-D | Shielded | Housing/Shell (Unthreaded) | Panel Mount | Gold | 0.043 in | 0.05 in | 26 AWG | |
NorComp Inc. | Black | 60 VDC | Liquid Crystal Polymer (LCP) | 125 °C | -40 C | Brass | Signal | Nickel Plated Zinc Alloy | UL94 V-0 | 30 Áin | 0.76 Ám | 2 | 9 | 2 A | Plug Male Pins | D-Type Micro-D | Shielded | Housing/Shell (Unthreaded) | Panel Mount | Gold | 0.043 in | 0.05 in | 26 AWG | |
NorComp Inc. | Black | 60 VDC | Liquid Crystal Polymer (LCP) | 125 °C | -40 C | Brass | Signal | Nickel Plated Zinc Alloy | UL94 V-0 | 15 µin | 0.38 µm | 2 | 9 | 2 A | Plug Male Pins | D-Type Micro-D | Shielded | Housing/Shell (Unthreaded) | Panel Mount Through Hole | Gold | 0.043 in | 0.05 in | Solder | |
 NorComp Inc. | Black | 60 VDC | Liquid Crystal Polymer (LCP) | 125 °C | -40 C | Brass | Signal | Nickel Plated Zinc Alloy | UL94 V-0 | 15 µin | 0.38 µm | 2 | 9 | 2 A | Receptacle Female Sockets | D-Type Micro-D | Shielded | Housing/Shell (Unthreaded) | Panel Mount | Gold | 0.043 in | 0.05 in | 26 AWG | |
NorComp Inc. | Black | 60 VDC | Liquid Crystal Polymer (LCP) | 125 °C | -40 C | Brass | Signal | Nickel Plated Zinc Alloy | UL94 V-0 | 30 Áin | 0.76 Ám | 2 | 9 | 2 A | Receptacle Female Sockets | D-Type Micro-D | Shielded | Housing/Shell (Unthreaded) | Panel Mount | Gold | 0.043 in | 0.05 in | 26 AWG |
