MPXHZ6115 Series
Manufacturer: Freescale Semiconductor - NXP
Beta
⌘K
SENSOR 16.68PSIA 0.13" 4.7V SSOP
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply [Min] | Voltage - Supply [Max] | Port Size | Port Size | Accuracy | Applications | Maximum Pressure | Maximum Pressure | Port Style | Features | Package / Case [y] | Package / Case [x] | Package / Case | Termination Style | Operating Pressure [Max] | Operating Pressure [Min] | Operating Pressure [Min] | Operating Pressure [Max] | Output Type | Supplier Device Package | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Freescale Semiconductor - NXP | 125 °C | -40 °C | 4.75 V | 5.25 V | 0.13 " | 3.3 mm | 1.5 % | Board Mount | 400 kPa | 58.02 PSI | Barbless | Temperature Compensated | 8.5 mm | 0.335 in | 8-SOIC Top Port | Gull Wing | 115 kPa | 2.18 PSI | 15 kPa | 16.68 PSI | Analog Voltage | 8-SSOP | Surface Mount |
