E36SR Series
Manufacturer: Delta Electronics
Beta
⌘K
ISOLATED DC/DC CONVERTERS - THROUGH HOLE DC/DC CONVERTER, 1/8 BRICK, 3.3V, 20A
| Part | Efficiency | Current - Output (Max) [Max] | Voltage - Input (Max) [Max] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Operating Temperature [Max] | Operating Temperature [Min] | Number of Outputs | Mounting Type | Voltage - Isolation | Voltage - Input (Min) [Min] | Power (Watts) | Voltage - Output 1 | Applications | Type | Control Features | Features | Package / Case | Size / Dimension [y] | Size / Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | 88 % | 20 A | 75 V | 0.9 in | 0.36 in | 2.3 in | 58.4 mm | 9.1 mm | 22.9 mm | 122 °C | -40 C | 1 | Through Hole | 2250 VDC | 18 V | 75 W | 3.3 V | ITE (Commercial) | Isolated Module | Active Low Enable | OCP OTP OVP Remote On/Off UVLO | 8-DIP Module 1/8 Brick | ||
 Delta Electronics | 89 % | 15 A | 75 V | 0.9 in | 0.5 in | 2.3 in | 58.4 mm | 85 °C | -40 C | 1 | Through Hole | 2250 VDC | 18 V | 75 W | 5 V | ITE (Commercial) | Isolated Module | Active Low Enable | OCP OTP OVP Remote On/Off UVLO | 8-DIP Module 1/8 Brick | 22.9 mm | 12.7 mm |
