3125-2 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN PC PIN CIRC .040DIA GOLD
| Part | Mounting Hole Diameter [diameter] | Mounting Hole Diameter [diameter] | Contact Material | Pin Size - Above Flange [diameter] | Pin Size - Above Flange | Insulation | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Length - Overall [x] | Length - Overall [x] | Board Thickness | Board Thickness | Contact Finish | Flange Diameter [diameter] | Flange Diameter [diameter] | Termination | Length - Above Flange | Length - Above Flange [x] | Length - Below Flange [x] | Length - Below Flange [x] | Terminal Style | Terminal Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | 0.043 in | 1.09 mm | Brass Alloy | 0.04 in | 1.02 mm | Non-Insulated | Through Hole | 50 µin | 1.27 µm | 0.402 " | 10.2 mm | 1.57 mm | 0.062 " | Gold | 0.071 in | 1.8 mm | Swage | 3.81 mm | 0.15 in | 2.08 mm | 0.082 " | Single End | PC Pin |
 Mill-Max Manufacturing Corp. | 0.043 in | 1.09 mm | Brass Alloy | 0.04 in | 1.02 mm | Non-Insulated | Through Hole | 10 Áin | 0.25 Ám | 0.402 " | 10.2 mm | 1.57 mm | 0.062 " | Gold | 0.071 in | 1.8 mm | Swage | 3.81 mm | 0.15 in | 2.08 mm | 0.082 " | Single End | PC Pin |
 Mill-Max Manufacturing Corp. | 0.043 in | 1.09 mm | Brass Alloy | 0.04 in | 1.02 mm | Non-Insulated | Through Hole | 200 Áin | 5.08 Ám | 0.402 " | 10.2 mm | 1.57 mm | 0.062 " | Tin | 0.071 in | 1.8 mm | Swage | 3.81 mm | 0.15 in | 2.08 mm | 0.082 " | Single End | PC Pin |
 Mill-Max Manufacturing Corp. | 0.043 in | 1.09 mm | Brass Alloy | 0.04 in | 1.02 mm | Non-Insulated | Through Hole | 200 Áin | 5.08 Ám | 0.402 " | 10.2 mm | 1.57 mm | 0.062 " | Tin-Lead | 0.071 in | 1.8 mm | Swage | 3.81 mm | 0.15 in | 2.08 mm | 0.082 " | Single End | PC Pin |
