M Series

Manufacturer: Panasonic Electronic Components

Catalog

CAP ALUMINUM LYTIC 33UF 50V 20% (5 X 11MM) RADIAL 2.5MM 0.11A 2000H 85°C AMMO AUTOMOTIVE AEC-Q200

Part	Polarization	Size / Dimension [diameter]	Size / Dimension [diameter]	Package / Case	Ripple Current @ Low Frequency	Capacitance	Voltage - Rated	Lifetime @ Temp.	Mounting Type	Ripple Current @ High Frequency	Height - Seated (Max) [Max]	Height - Seated (Max)	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Lead Spacing	Lead Spacing	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]
Panasonic Electronic Components ECA-1HM330I	Polar	0.197 in	5 mm	Can Radial	110 mA	33 ÁF	50 VDC	2000 Hrs	Through Hole	187 mA	0.472 in	12 mm	85 °C	-40 C	General Purpose	2.5 mm	0.098 in	20 %
Panasonic Electronic Components ECA-0JM682
Panasonic Electronic Components ECA-1AM472B	Polar	0.492 in	12.5 mm	Can Radial	1.2 A	4700 µF	10 V	2000 Hrs	Through Hole	2.04 A	1.063 in		85 °C	-40 C	General Purpose	5 mm	0.197 "	20 %	27 mm
Panasonic Electronic Components ECA-1CM221	Polar	0.248 "	6.3 mm	Can Radial	280 mA	220 µF	16 V	2000 Hrs	Through Hole	476 mA	0.48 in	12.2 mm	85 °C	-40 C	General Purpose	2.5 mm	0.098 in	20 %
Panasonic Electronic Components ECA-2WM330	Polar	0.63 in	16 mm	Can Radial		33 ÁF	450 V	2000 Hrs	Through Hole	484.5 mA		33.5 mm	85 °C	-25 °C	General Purpose	7.5 mm	0.295 in	20 %		1.319 in
Panasonic Electronic Components ECA-2EM3R3	Polar	0.315 in	8 mm	Can Radial	72 mA	3.3 µF	250 V	2000 Hrs	Through Hole	122.4 mA			85 °C	-25 °C	General Purpose	3.5 mm	0.138 in	20 %	0.492 in		12.5 mm
Panasonic Electronic Components ECA-1VM331B	Polar	0.394 in	10 mm	Can Radial	440 mA	330 µF	35 V	2000 Hrs	Through Hole	748 mA	0.531 in		85 °C	-40 C	General Purpose	5 mm	0.197 "	20 %	13.5 mm
Panasonic Electronic Components ECA-0JM331B	Polar	0.248 "	6.3 mm	Can Radial		330 µF	6.3 VDC	2000 Hrs	Through Hole	510 mA	0.48 in	12.2 mm	85 °C	-40 C	General Purpose	5 mm	0.197 "	20 %
Panasonic Electronic Components ECA-2DM2R2B	Polar	0.248 "	6.3 mm	Can Radial	50 mA	2.2 µF	200 VDC	2000 Hrs	Through Hole	85 mA	0.48 in	12.2 mm	85 °C	-25 °C	General Purpose	5 mm	0.197 "	20 %
Panasonic Electronic Components ECA-1HM220I	Polar	0.197 in	5 mm	Can Radial	100 mA	22 µF	50 VDC	2000 Hrs	Through Hole	170 mA	0.472 in	12 mm	85 °C	-40 C	General Purpose	2.5 mm	0.098 in	20 %
