Fixed Terminal Blocks FRONT 2,5-V/SA10/ 7
Fixed Terminal Blocks FRONT 2,5-V/SA10/ 7
| Part | Torque - Screw [Max] | Torque - Screw [Min] | Torque - Screw [Min] | Torque - Screw [Max] | Contact Material - Plating | Operating Temperature [Min] | Operating Temperature [Max] | Housing Material | Positions Per Level | Pitch | Pitch | Mounting Type | Wire Gauge [Max] | Wire Gauge [Min] | Voltage | Wire Termination | Number of Levels | Color | Current | Mating Orientation | Features | Positions Per Level [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 4.4 Lb-In | 3.5 Lb-In | 0.4 Nm | 0.5 Nm | Copper Alloy - Tin Plated | -40 C | 105 ░C | Polyamide (PA) Nylon | 2 | 0.197 in | 5 mm | Through Hole | 30 AWG | 12 AWG | 300 VDC | Screw | 1 | Green | 10 A | Vertical with Board | ||
 Phoenix Contact | 6 | 0.197 in | 5 mm | Through Hole | 30 AWG | 12 AWG | 300 VDC | Screw | 1 | Green | 10 A | Vertical with Board | ||||||||||
Phoenix Contact | 1 | Through Hole | 30 AWG | 12 AWG | 300 VDC | Screw | 1 | Blue | 17 A | Vertical with Board | Interlocking (Side) | |||||||||||
 Phoenix Contact | 0.197 in | 5 mm | Through Hole | 30 AWG | 12 AWG | 300 VDC | Screw - Rising Cage Clamp | 1 | Black | 20 A | Horizontal with Board | Interlocking (Side) | 7 | |||||||||
 Phoenix Contact | 4 | 0.197 in | 5 mm | Through Hole | 30 AWG | 12 AWG | 300 VDC | Screw | 1 | Green | 10 A | Vertical with Board | ||||||||||
 Phoenix Contact | 6 | 0.197 in | 5 mm | Through Hole | 30 AWG | 12 AWG | 300 VDC | Screw - Rising Cage Clamp | 1 | Green | 20 A | Horizontal with Board | Interlocking (Side) | |||||||||
Phoenix Contact | 0.197 in | 5 mm | Through Hole | 30 AWG | 12 AWG | 300 VDC | Screw | 1 | Green | 10 A | Vertical with Board | 7 | ||||||||||
Phoenix Contact | 9 | 0.197 in | 5 mm | Through Hole | 30 AWG | 12 AWG | 300 VDC | Screw | 1 | Green | 10 A | Vertical with Board |
