XRCFD Series

Catalog

CRYSTAL

Part	Mounting Type	Frequency Tolerance	Load Capacitance	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Type	ESR (Equivalent Series Resistance)	Frequency Stability	Operating Temperature [Max]	Operating Temperature [Min]	Operating Mode	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Package / Case	Frequency
Murata Electronics XRCFD26M000FXQ53R0
Murata Electronics XRCFD27M120F2N51R0	Surface Mount	20 ppm	8 pF	1.6 mm	1.2 mm	0.047 in	0.063 "	MHz Crystal	150 Ohms	30 ppm	85 °C	-40 C	Fundamental	0.35 mm	0.014 "	4-SMD No Lead	27.12 MHz
Murata Electronics XRCFD26M000FXQ50R0
Murata Electronics XRCFD26M000FYQ01R0	Surface Mount	20 ppm	8 pF	1.6 mm	1.2 mm	0.047 in	0.063 "	MHz Crystal	150 Ohms		85 °C	-30 ░C	Fundamental	0.35 mm	0.014 "	4-SMD No Lead	26 MHz
