71ADF36 Series
Manufacturer: Grayhill Inc.
Beta
⌘K
71ADF36-03-1-AJN
| Part | Actuator Type | Contact Material | Current Rating (Amps) | Number of Decks | Circuit per Deck | Contact Timing | Depth Behind Panel [custom] | Angle of Throw | Index Stops | Number of Poles per Deck | Voltage Rating - AC | Actuator Length [x] | Voltage Rating - DC | Termination Style | Mounting Type | Number of Positions [Max] | Number of Positions [Min] | Number of Decks [custom] | Depth Behind Panel [z] | Depth Behind Panel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Grayhill Inc. | Flatted (3.17mm Dia) | Silver Alloy | 250 mA | 3 | SP10T | Non-Shorting (BBM) | 30.4 mm | 36 ° | Adjustable | 1 | 115 V | 9.53 mm | 30 V | PC Pin | Panel Mount Right Angle Through Hole | |||||
 Grayhill Inc. | Flatted (3.17mm Dia) | Silver Alloy | 250 mA | DP5T | Non-Shorting (BBM) | 36 ° | Adjustable | 2 | 115 V | 9.53 mm | 30 V | PC Pin | Panel Mount Right Angle Through Hole | 5 | 2 | 1 | 19.33 mm | |||
 Grayhill Inc. | Flatted (3.17mm Dia) | Silver Alloy | 250 mA | 2 | SP10T | Non-Shorting (BBM) | 36 ° | Adjustable | 1 | 115 V | 9.53 mm | 30 V | PC Pin | Panel Mount Right Angle Through Hole | 24.87 mm | |||||
Grayhill Inc. | Flatted (3.17mm Dia) | Silver Alloy | 250 mA | 2 | SP10T | Shorting (MBB) | 36 ° | Adjustable | 1 | 115 V | 9.53 mm | 30 V | PC Pin | Panel Mount Right Angle Through Hole | 24.87 mm | |||||
 Grayhill Inc. | Flatted (3.17mm Dia) | Silver Alloy | 250 mA | 2 | DP5T | Non-Shorting (BBM) | 36 ° | Adjustable | 2 | 115 V | 9.53 mm | 30 V | PC Pin | Panel Mount Right Angle Through Hole | 5 | 2 | 24.87 mm |
