General Purpose Relays Relay Plug-In DPDT 8A 120VAC
General Purpose Relays Relay Plug-In DPDT 8A 120VAC
| Part | Mounting Type | Must Release Voltage | Coil Voltage | Approval Agency | Contact Form | Coil Type | Coil Current | Switching Voltage | Coil Resistance | Operate Time | Contact Rating (Current) | Operating Temperature [Min] | Operating Temperature [Max] | Must Operate Voltage | Termination Style | Contact Material | Release Time | Relay Type | Features | Coil Voltage [Max] | Coil Voltage [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 IDEC | Socketable | 36 VAC | 120 VAC | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 7.5 mA | 250 VAC | 6.4 kOhms | 15 ms | 12 A | -40 °C | 70 °C | 96 VAC | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 10 ms | General Purpose | |||
IDEC | Socketable | 2.4 VDC | 24 VDC | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 25.7 mA | 250 VAC | 1.08 kOhms | 20 ms | 12 A | -40 °C | 70 °C | 16.8 VDC | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 20 ms | General Purpose | Diode Lighted Indicator | ||
 IDEC | Socketable | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 5.3 mA | 125 VDC 250 VAC | 18.87 kOhms | 15 ms | 12 A | -40 °C | 70 °C | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 10 ms | General Purpose | 110 VDC | 100 VDC | ||||
IDEC | Socketable | 0.5 VDC | 5 VDC | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 110 mA | 125 VDC 250 VAC | 47.2 Ohms | 15 ms | 12 A | -40 °C | 70 °C | 3.5 VDC | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 10 ms | General Purpose | Diode Lighted Indicator Reverse Coil Polarity | ||
IDEC | Socketable | 1.2 VDC | 12 VDC | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 48 mA | 250 VAC | 271 Ohms | 15 ms | 12 A | -40 °C | 70 °C | 8.4 VDC | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 10 ms | General Purpose | Lighted Indicator | ||
IDEC | Socketable | 1.2 VDC | 12 VDC | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 44.2 mA | 30 VDC 250 VAC | 271 Ohms | 15 ms | 16 A | -40 °C | 70 °C | 8.4 VDC | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 10 ms | General Purpose | |||
IDEC | Socketable | 7.2 VAC | 24 VAC | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 41.1 mA | 250 VAC | 243 Ohms | 15 ms | 12 A | -40 °C | 70 °C | 19.2 VAC | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 10 ms | General Purpose | Lighted Indicator | ||
IDEC | Socketable | 2.4 VDC | 24 VDC | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 22.1 mA | 250 VAC | 1.08 kOhms | 20 ms | 12 A | -40 °C | 70 °C | 16.8 VDC | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 20 ms | General Purpose | Diode | ||
IDEC | Socketable | 36 VAC | 120 VAC | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 7.5 mA | 125 VDC 250 VAC | 6.4 kOhms | 15 ms | 12 A | -40 °C | 70 °C | 96 VAC | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 10 ms | General Purpose | RC Circuit | ||
IDEC | Socketable | 66 VAC | 220 VAC/DC | CE CSA cURus VDE | SPDT (1 Form C) | Non Latching | 4.1 mA | 125 VDC 250 VAC | 21.53 kOhms | 15 ms | 12 A | -40 °C | 70 °C | 176 VAC | Plug In Quick Connect - 0.187" (4.7mm) | Silver Nickel (AgNi) | 10 ms | General Purpose |
