PEC25 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 25POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Shape	Insulation Color	Insulation Height	Insulation Height	Style	Contact Type	Mounting Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Post	Material Flammability Rating	Contact Length - Mating	Contact Length - Mating	Insulation Material	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Number of Positions	Contact Material	Termination	Pitch - Mating	Pitch - Mating	Current Rating (Amps)	Number of Rows	Contact Length - Post [custom]	Contact Length - Post [custom]	Fastening Type	Number of Positions Loaded	Shrouding	Overall Contact Length	Overall Contact Length	Contact Length - Post	Contact Length - Post	Number of Rows [custom]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Overall Contact Length	Insulation Height [z]	Insulation Height [z]	Overall Contact Length [x]	Overall Contact Length [x]
Sullins Connector Solutions PEC25SBBN	2.54 µm	100 µin	Square	Black	3.56 mm	0.14 in	Board to Board Cable	Male Pin	Right Angle Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.23 in	5.84 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	25	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A	1	5.08 mm	0.2 "	Push-Pull	All	Unshrouded
Sullins Connector Solutions PEC25SAGN	2.54 µm	100 µin	Square	Black	2.54 mm	0.1 in	Board to Board Cable	Male Pin	Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.23 in	5.84 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	25	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A	1			Push-Pull	All	Unshrouded	26.67 mm	1.05 in	0.72 "	18.29 mm
Sullins Connector Solutions PEC25SAFN	2.54 µm	100 µin	Square	Black	2.54 mm	0.1 in	Board to Board Cable	Male Pin	Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.23 in	5.84 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	25	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A	1	15.75 mm	0.62 "	Push-Pull	All	Unshrouded	24.13 mm	0.95 in
Sullins Connector Solutions PEC25DFBN	2.54 µm	100 µin	Square	Black	2.54 mm	0.1 in	Board to Board Cable	Male Pin	Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.318 in	8.08 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	50	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A				Push-Pull	All	Unshrouded	16.21 mm	0.638 in	0.22 in	5.58 mm	2	0.1 in	2.54 mm
Sullins Connector Solutions PEC25SGAN	2.54 µm	100 µin	Square	Black	3.56 mm	0.14 in	Board to Board Cable	Male Pin	Right Angle Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.318 in	8.08 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	25	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A	1			Push-Pull	All	Unshrouded			0.1 in	2.54 mm
Sullins Connector Solutions PEC25SBCN	2.54 µm	100 µin	Square	Black	3.56 mm	0.14 in	Board to Board Cable	Male Pin	Right Angle Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.23 in	5.84 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	25	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A	1			Push-Pull	All	Unshrouded			0.3 in	7.62 mm
Sullins Connector Solutions PEC25SFCN	2.54 µm	100 µin	Square	Black	2.54 mm	0.1 in	Board to Board Cable	Male Pin	Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.318 in	8.08 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	25	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A	1			Push-Pull	All	Unshrouded	18.75 mm		0.32 in	8.13 mm				0.738 in
Sullins Connector Solutions PEC25DFCN	2.54 µm	100 µin	Square	Black	2.54 mm	0.1 in	Board to Board Cable	Male Pin	Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.318 in	8.08 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	50	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A				Push-Pull	All	Unshrouded	18.75 mm		0.32 in	8.13 mm	2	0.1 in	2.54 mm	0.738 in
Sullins Connector Solutions PEC25DBAN	2.54 µm	100 µin	Square	Black			Board to Board Cable	Male Pin	Right Angle Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.23 in	5.84 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	50	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A				Push-Pull	All	Unshrouded			0.1 in	2.54 mm	2	0.1 in	2.54 mm		6.1 mm	0.24 in
Sullins Connector Solutions PEC25DADN	2.54 µm	100 µin	Square	Black	2.54 mm	0.1 in	Board to Board Cable	Male Pin	Through Hole	100 çin	2.54 çm	Tin	UL94 V-0	0.23 in	5.84 mm	Polybutylene Terephthalate (PBT)	-65 ░C	125 °C	Header Breakaway	50	Phosphor Bronze	Solder	0.1 "	2.54 mm	3 A				Push-Pull	All	Unshrouded			0.42 in	10.67 mm	2	0.1 in	2.54 mm				19.05 mm	0.75 in
