630-25W Series
Manufacturer: EDAC Inc.
Beta
⌘K
D-SUB MIXED CONTACT CONNECTORS RIGHT-ANGLE POWER COMBO D-SUB CONNECTOR
| Part | Contact Material | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Color | Flange Feature | Number of Positions [custom] | Number of Positions [custom] | Shell Size, Connector Layout | Shell Size, Connector Layout [custom] | Material Flammability Rating | Current Rating (Amps) | Contact Finish | Shell Material, Finish | Features | Mounting Type | Number of Rows [custom] | Backset Spacing | Backset Spacing | Contact Finish Thickness | Connector Style | Connector Type | Termination | Contact Type | Number of Positions [custom] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | 4-40 | 3 | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | 20A 5A | Gold | Nickel Plated Steel | Board Lock Mounting Brackets | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Flash | Combo D-Sub | Receptacle Female Sockets | Solder | Signal and Power | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | 4-40 | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | Gold | Board Lock | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Flash | Combo D-Sub | Receptacle Female Sockets | Solder | Coax Signal | 3 | |||||||
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | Housing/Shell | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | Gold | Nickel Plated Steel | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | Solder | Coax Signal | 3 | 30 Áin | 0.76 Ám | 4-40 | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | Housing/Shell (M3) | 3 | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | 10A 5A | Gold | Mounting Brackets | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | Solder | Signal and Power | 30 Áin | 0.76 Ám | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | Housing/Shell | 3 | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | 10A 5A | Gold | Nickel Plated Steel | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | Solder | Signal and Power | 30 Áin | 0.76 Ám | 4-40 | ||||
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | 4-40 | 3 | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | 20A 5A | Gold | Nickel Plated Steel | Board Lock | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | Solder | Signal and Power | 30 Áin | 0.76 Ám | ||||
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | 4-40 | 3 | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | Gold | Nickel Plated Steel | Board Lock Mounting Brackets | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Flash | Combo D-Sub | Receptacle Female Sockets | Solder | Signal and Power | 5 A 40 A | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | Housing/Shell (Unthreaded) | 3 | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | Gold | Nickel Plated Steel | Shielded | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Flash | Combo D-Sub | Receptacle Female Sockets | Solder | Signal and Power | 5 A 30 A | |||||
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | 4-40 | 3 | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | 10A 5A | Gold | Board Lock | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Flash | Combo D-Sub | Receptacle Female Sockets | Solder | Signal and Power | ||||||
 EDAC Inc. | Copper Alloy | 125 VDC | -55 C | 125 °C | Polyester Thermoplastic | Black | M3 | 22 | (DC C) - 25W3 | 4 | UL94 V-0 | Gold | Board Lock Mounting Brackets | Right Angle Through Hole | 2 | 9.4 mm | 0.37 in | Combo D-Sub | Receptacle Female Sockets | Solder | Coax Signal | 3 | 30 Áin | 0.76 Ám |
