039735 Series
Manufacturer: Molex
Beta
⌘K
TERM BLOCK HDR 6POS VERT 5.08MM
| Part | Number of Levels | Contact Tail Length | Contact Tail Length | Voltage - UL | Current - UL | Features | Contact Material | Insulation Height | Insulation Height | Number of Positions | Color | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Termination Style | Contact Mating Finish | Material Flammability Rating | Pitch [x] | Pitch [x] | Type | Positions Per Level | Header Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | 1 | 3.56 mm | 0.14 in | 250 V | 12 A | Retention Latches | Brass | 0.75 in | 19.05 mm | 6 | Green | Through Hole | -40 °C | 105 ░C | Solder | Tin | UL94 V-0 | 0.2 in | 5.08 mm | Header Female Sockets | 6 | Vertical |
Molex | 1 | 3.56 mm | 0.14 in | 250 V | 12 A | Retention Latches | Brass | 0.75 in | 19.05 mm | 12 | Green | Through Hole | -40 °C | 105 ░C | Solder | Tin | UL94 V-0 | 0.2 in | 5.08 mm | Header Female Sockets | 12 | Vertical |
Molex | 1 | 3.56 mm | 0.14 in | 250 V | 12 A | Retention Latches | Brass | 0.75 in | 19.05 mm | 9 | Green | Through Hole | -40 °C | 105 ░C | Solder | Tin | UL94 V-0 | 0.2 in | 5.08 mm | Header Female Sockets | 9 | Vertical |
Molex | 1 | 3.56 mm | 0.14 in | 250 V | 12 A | Retention Latches | Brass | 0.75 in | 19.05 mm | Green | Through Hole | -40 °C | 105 ░C | Solder | Tin | UL94 V-0 | 0.2 in | 5.08 mm | Header Female Sockets | 3 | Vertical | |
 Molex | 1 | 3.56 mm | 0.14 in | 250 V | 12 A | Retention Latches | Brass | 0.75 in | 19.05 mm | 11 | Green | Through Hole | -40 °C | 105 ░C | Solder | Tin | UL94 V-0 | 0.2 in | 5.08 mm | Header Female Sockets | 11 | Vertical |
Molex | 1 | 3.56 mm | 0.14 in | 250 V | 12 A | Retention Latches | Brass | 0.75 in | 19.05 mm | Green | Through Hole | -40 °C | 105 ░C | Solder | Tin | UL94 V-0 | 0.2 in | 5.08 mm | Header Female Sockets | 5 | Vertical |
