887-040 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 40POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Contact Material | Read Out | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Termination | Card Type | Gender | Number of Positions | Color | Contact Type | Contact Finish | Mounting Type | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Termination Rows | Number of Positions/Bay/Row [custom] | Number of Rows | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | Dual | 2 | 0.25 Ám | 10 Áin | 20 Bay/Row | Solder | Non Specified - Dual Edge | Female | 40 | Black | Cantilever | Gold | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | |||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Single | 0.25 Ám | 10 Áin | Solder | Non Specified - Single Edge | Female | 40 | Black | Cantilever | Gold | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 1 | 40 | 1 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | Dual | 2 | 0.25 Ám | 10 Áin | 20 Bay/Row | Solder | Non Specified - Dual Edge | Female | 40 | Black | Cantilever | Gold | Board Edge Straddle Mount | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Card Extender | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Single | 0.25 Ám | 10 Áin | Wire Wrap | Non Specified - Single Edge | Female | 40 | Black | Cantilever | Gold | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 1 | 40 | 1 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | Dual | 2 | 0.25 Ám | 10 Áin | 20 Bay/Row | Solder | Non Specified - Dual Edge | Female | 40 | Black | Cantilever | Gold | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Single | 0.25 Ám | 10 Áin | Solder | Non Specified - Single Edge | Female | 40 | Black | Cantilever | Gold | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 1 | 40 | 1 | |||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | Dual | 2 | 0.25 Ám | 10 Áin | 20 Bay/Row | Wire Wrap | Non Specified - Dual Edge | Female | 40 | Black | Cantilever | Gold | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | Dual | 2 | 0.25 Ám | 10 Áin | 20 Bay/Row | Wire Wrap | Non Specified - Dual Edge | Female | 40 | Black | Cantilever | Gold | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Single | 0.25 Ám | 10 Áin | Solder | Non Specified - Single Edge | Female | 40 | Black | Cantilever | Gold | Through Hole | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 1 | 40 | 1 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Copper Alloy | Dual | 2 | 0.25 Ám | 10 Áin | 20 Bay/Row | Solder | Non Specified - Dual Edge | Female | 40 | Black | Cantilever | Gold | Board Edge Straddle Mount | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Card Extender |
