074323 Series
Manufacturer: Molex
Beta
⌘K
CONN PLUG DVI-D 18POS SOLDER
| Part | Mounting Type | Number of Ports | Shielding | Connector Type | Material Flammability Rating | Termination | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Insulation Color | Contact Finish | Voltage - Rated | Current Rating (Amps) | Mounting Feature | Shell/Shielding Material | Number of Contacts [custom] | Number of Contacts |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Free Hanging (In-Line) | 1 | Shielded | DVI-D Single Link | UL94 V-0 | Solder | Plug | 85 °C | -20 C | Black | Gold | 40 VAC | 3 A | Flange | Steel Alloy | ||
Molex | Through Hole | 1 | Shielded | DVI-I Single Link | UL94 V-0 | Solder | Plug | 85 °C | -20 C | Black | Gold | 40 VAC | 3 A | Flange Vertical | Steel Alloy | 23 | |
 Molex | Free Hanging (In-Line) | 1 | Shielded | DVI-I Dual Link | UL94 V-0 | Solder | Plug | 85 °C | -20 C | Black | Gold | 40 VAC | 3 A | Flange | Steel Alloy | 29 | |
Molex | Through Hole | 1 | Shielded | DVI-A | UL94 V-0 | Solder | Plug | 85 °C | -20 C | Black | Gold | 40 VAC | 3 A | Flange Vertical | Steel Alloy | 23 | |
 Molex | Free Hanging (In-Line) | 1 | Shielded | DVI-D Dual Link | UL94 V-0 | Solder | Plug | 85 °C | -20 C | Black | Gold | 40 VAC | 3 A | Flange | Steel Alloy | 24 | |
 Molex | Through Hole | 1 | Shielded | DVI-D Single Link | UL94 V-0 | Solder | Plug | 85 °C | -20 C | Black | Gold | 40 VAC | 3 A | Flange Vertical | Steel Alloy | ||
Molex | Free Hanging (In-Line) | 1 | Shielded | DVI-I Single Link | UL94 V-0 | Solder | Plug | 85 °C | -20 C | Black | Gold | 40 VAC | 3 A | Flange | Steel Alloy | 23 |
