282852 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
(282852-3) TERMI-BLOK PCB MOUNT 180 3P.
| Part | Number of Levels | Clamp Material - Plating | Pitch [x] | Pitch [x] | Wire Termination | Mating Orientation | Contact Material - Plating [custom] | Positions Per Level | Color | Screw Thread | Current | Screw Material - Plating | Wire Gauge [Max] | Wire Gauge [Min] | Mounting Type | Features | Torque - Screw | Torque - Screw | Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 1 | Brass - Nickel Plated | 0.394 in | 10 mm | Screw - Rising Cage Clamp | Vertical with Board | Brass - Tin Plated | 3 | Green | M3 | 17.5 A | Brass - Nickel Plated | 30 AWG | 12 AWG | Through Hole | Interlocking (Side) | 0.79 Nm | 7 Lb-In | 600 V |
