POE15M Series
Manufacturer: Phihong USA
Beta
⌘K
IEEE802.3AF - POE DESKTOP C6 2.5
| Part | Input Connector | Output Connector | Features | Number of Ports | Standard Number | Voltage - Output | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Power (Watts) - Per Port | Voltage - Input [Max] | Voltage - Input [Min] | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] | Current - Output | Mounting Type | Type | Compliance | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phihong USA | IEC 320-C6 (Power) RJ45 (Data) | RJ45 (Data Power) | OCP OVP SCP | 1 | 60950-1 | 56 V | 106.2 mm | 27.3 mm | 39.5 mm | 1.56 " | 4.18 " | 1.07 in | 15.4 W | 264 VAC | 90 VAC | cULus IEC | -20 ░C | 50 °C | 275 mA | Desktop | Passive Injector | IEEE802.3af | |
 Phihong USA | IEC 320-C6 (Power) RJ45 (Data) | RJ45 (Data Power) | OCP OVP SCP | 1 | 60950-1 | 56 V | 106.2 mm | 27.3 mm | 39.5 mm | 1.56 " | 4.18 " | 1.07 in | 15.4 W | 264 VAC | 90 VAC | cULus IEC | -20 ░C | 50 °C | 275 mA | Desktop | Passive Injector | Level VI | |
 Phihong USA | IEC 320-C6 (Power) RJ45 (Data) | RJ45 (Data Power) | OCP OVP SCP | 1 | 60950-1 | 56 V | 106.2 mm | 27.3 mm | 39.5 mm | 1.56 " | 4.18 " | 1.07 in | 15.4 W | 264 VAC | 90 VAC | cULus IEC | -20 ░C | 50 °C | 275 mA | Desktop | Passive Injector | IEEE802.3af | |
 Phihong USA | IEC 320-C6 (Power) RJ45 (Data) | RJ45 (Data Power) | OCP OVP SCP | 1 | 56 V | 106.2 mm | 27.3 mm | 39.5 mm | 1.56 " | 4.18 " | 1.07 in | 15.4 W | 264 VAC | 90 VAC | CE cULus | -20 ░C | 50 °C | 275 mA | Desktop | Passive Injector | Level VI | ||
 Phihong USA | IEC 320-C6 (Power) RJ45 (Data) | RJ45 (Data Power) | OCP OVP SCP | 1 | 56 V | 106.2 mm | 27.3 mm | 39.5 mm | 1.56 " | 4.18 " | 1.07 in | 15.4 W | 264 VAC | 90 VAC | CE cULus | -20 ░C | 50 °C | 275 mA | Desktop | Midspan Injector | IEEE802.3af |
