CRF0805 Series
Manufacturer: Bourns Inc.
Beta
⌘K
RES 0.02 OHM 1% 1/2W 0805
| Part | Features | Number of Terminations [custom] | Height - Seated (Max) [Max] | Height - Seated (Max) | Temperature Coefficient | Ratings | Power (Watts) | Power (Watts) | Package / Case | Composition | Operating Temperature [Max] | Operating Temperature [Min] | Resistance | Tolerance | Supplier Device Package | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | Automotive AEC-Q200 Current Sense Moisture Resistant | 2 | 0.031 in | 0.8 mm | 100 ppm/°C | AEC-Q200 | 0.5 W | 0.5 W | 0805 | Metal Element | 170 °C | -55 C | 0.02 Ohms | 1 % | 0805 | 2 mm | 1.25 mm | 0.049 " | 0.079 in |
 Bourns Inc. | Automotive AEC-Q200 Current Sense Moisture Resistant | 2 | 0.031 in | 0.8 mm | 50 ppm/░C | AEC-Q200 | 0.5 W | 0.5 W | 0805 | Metal Element | 170 °C | -55 C | 0.02 Ohms | 1 % | 0805 | 2 mm | 1.25 mm | 0.049 " | 0.079 in |
Bourns Inc. | Automotive AEC-Q200 Current Sense Moisture Resistant | 2 | 0.031 in | 0.8 mm | 50 ppm/░C | AEC-Q200 | 0.5 W | 0.5 W | 0805 | Metal Element | 170 °C | -55 C | 9 mOhms | 1 % | 0805 | 2 mm | 1.25 mm | 0.049 " | 0.079 in |
Bourns Inc. | Automotive AEC-Q200 Current Sense Moisture Resistant | 2 | 0.031 in | 0.8 mm | 100 ppm/°C | AEC-Q200 | 0.5 W | 0.5 W | 0805 | Metal Element | 170 °C | -55 C | 5 mOhms | 1 % | 0805 | 2 mm | 1.25 mm | 0.049 " | 0.079 in |
 Bourns Inc. | Automotive AEC-Q200 Current Sense Moisture Resistant | 2 | 0.031 in | 0.8 mm | 50 ppm/░C | AEC-Q200 | 0.5 W | 0.5 W | 0805 | Metal Element | 170 °C | -55 C | 10 mOhms | 1 % | 0805 | 2 mm | 1.25 mm | 0.049 " | 0.079 in |
