857-031 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 62POS 0.156
| Part | Mounting Type | Number of Rows [custom] | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Termination | Contact Material | Card Type | Pitch | Pitch | Termination Rows | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Positions | Gender | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Color | Number of Positions/Bay/Row [custom] | Material - Insulation | Number of Positions [custom] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Right Angle Through Hole | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Copper Alloy | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Dual | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 62 | Female | Semi Bellows | 0.25 Ám | 10 Áin | Black | 31 | Polyphenylene Sulfide (PPS) | ||
 EDAC Inc. | Right Angle Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Copper Alloy | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Single | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | Semi Bellows | 0.25 Ám | 10 Áin | Black | 31 | Polyphenylene Sulfide (PPS) | 31 | 1 | ||
 EDAC Inc. | Right Angle Through Hole | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Copper Alloy | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Dual | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 62 | Female | Semi Bellows | 0.25 Ám | 10 Áin | Black | 31 | Polyphenylene Sulfide (PPS) | ||
 EDAC Inc. | Right Angle Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Copper Alloy | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Single | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Female | Semi Bellows | 0.25 Ám | 10 Áin | Black | 31 | Polyphenylene Sulfide (PPS) | 31 | 1 | ||
 EDAC Inc. | Right Angle Through Hole | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Copper Alloy | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Dual | 4-40 Flush Mount Threaded Insert Top Opening | 62 | Female | Semi Bellows | 0.25 Ám | 10 Áin | Black | 31 | Polyphenylene Sulfide (PPS) | ||||
 EDAC Inc. | Right Angle Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Copper Alloy | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Single | 4-40 Flush Mount Threaded Insert Top Opening | Female | Semi Bellows | 0.25 Ám | 10 Áin | Black | 31 | Polyphenylene Sulfide (PPS) | 31 | 1 | ||||
 EDAC Inc. | Through Hole | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Copper Alloy | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Single | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Female | Semi Bellows | Black | 31 | Polyphenylene Sulfide (PPS) | 31 | 1 | ||||
 EDAC Inc. | Right Angle Through Hole | 2 | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Copper Alloy | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Dual | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 62 | Female | Semi Bellows | Black | 31 | Polyphenylene Sulfide (PPS) | ||||
 EDAC Inc. | Through Hole | 2 | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Copper Alloy | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Dual | 4-40 Flush Mount Threaded Insert Top Opening | 62 | Female | Semi Bellows | Black | 31 | Polyphenylene Sulfide (PPS) | ||||||
 EDAC Inc. | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Copper Alloy | Non Specified - Single Edge | 3.96 mm | 0.156 in | 1 | 125 °C | -40 C | Single | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Female | Semi Bellows | 0.25 Ám | 10 Áin | Black | 31 | Polyphenylene Sulfide (PPS) | 31 | 1 |
