WLS28 Series
Manufacturer: BANNER ENGINEERING
Catalog
LED WORK LIGHT, 1.04M, 30V, 4PIN M12 QD
...
| Part | Ingress Protection | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | Length | Length | Housing Material | Profile (W x H) [y] | Profile (W x H) [x] | Profile (W x H) [y] | Profile (W x H) [x] | Features | Luminous Flux | Illumination Color | Rated Life | Termination Style | Lens Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Length [x] | Length [x] | Luminous Flux [custom] | Luminous Flux [custom] | Luminous Flux [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IP50 | -40 °C | 70 °C | CE cULus | 38.98 in | 990 mm | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | 2800 lm | Cool White | 75000 Hours | Connector (M12) | Clear Flat | 12 V | 30 VDC | |||||
 BANNER ENGINEERING | IP50 | -40 °C | 70 °C | CE cULus | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | 2400 lm | Warm White | 75000 Hours | Connector (M12) | Diffused Flat | 12 V | 30 VDC | |||||||
 BANNER ENGINEERING | IP50 | -40 °C | 70 °C | CE cULus | 38.98 in | 990 mm | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | 2800 lm | Cool White | 75000 Hours | Connector (M12) | Clear Flat | 12 V | 30 VDC | |||||
 BANNER ENGINEERING | IP65 IP67 IP69K | -40 °C | 70 °C | CE cULus | 38.98 in | 990 mm | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | 2800 lm | Cool White | 75000 Hours | Connector (M12) | Clear Flat | 12 V | 30 VDC | |||||
BANNER ENGINEERING | IP50 | -40 °C | 70 °C | CE cULus | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | 2400 lm | Cool White | 75000 Hours | Connector (M12) | Clear Flat | 12 V | 30 VDC | |||||||
 BANNER ENGINEERING | IP50 | -40 °C | 70 °C | CE cULus | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | 600 lm 1425 lm | Red White | 75000 Hours | Connector (M12) | Diffused Flat | 12 V | 30 VDC | 44.49 in | 1130 mm | |||||
BANNER ENGINEERING | IP50 | -40 °C | 70 °C | CE cULus | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | 800 lm | Cool White | 75000 Hours | Connector (M12) | Clear Flat | 12 V | 30 VDC | |||||||
 BANNER ENGINEERING | IP50 | -40 °C | 70 °C | CE cULus | 22.44 in | 570 mm | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | Green Red White | 75000 Hours | Connector (M12) | Clear Flat | 12 V | 30 VDC | 1300 lm | 370 lm | 800 lm | |||
BANNER ENGINEERING | IP65 IP67 IP69K | -40 °C | 70 °C | CE cULus | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | 2400 lm | Cool White | 75000 Hours | Connector (M12) | Clear Flat | 12 V | 30 VDC | |||||||
 BANNER ENGINEERING | IP65 IP67 IP69K | -40 °C | 70 °C | CE cULus | 38.98 in | 990 mm | Aluminum (Al) | 21 mm | 28 mm | 0.83 in | 1.1 in | Cascadable | 2800 lm | Cool White | 75000 Hours | Connector (M12) | Diffused Flat | 12 V | 30 VDC |
